ATTACCO A SELLA saldatura a bicchiere
FUSION OUTLET socket welding
Articolo Ø uscita per tubo Peso
Item Ø out-put for pipe X* Y* A B D R Weight
mm mm mm mm g pezzi pezzi
pieces pieces
500 500882 50394
651045 110 164,0 125,0 58,0 425,0 730,9 1
560 500890 50394
651047 110 630 500898 50394 164,0 125,0 58,0 425,0 730,9 1
651046 125 400 500858 50366-50396 164,0 125,0 58,0 425,0 730,9 1
651048 125 450 500872 50396 164,0 125,0 58,0 425,0 730,9 1
500 500884 50396
560 500892 50396
X* Articolo matrice idonea Code 651049 125 630 500900 50396 164,0 125,0 58,0 425,0 730,9 1

suitable weld-in-saddle
Y* Articolo fresa idonea
Code suitable miller

INNESTO DIRETTO saldatura a bicchiere
DIRECT JOINT socket welding
Articolo Peso
Item DN /OD SDR A B C D H G Weight

mm mm mm mm mm mm g pezzi pezzi
pieces pieces
65132 20x50~400 5 14,8 29,5 10,0 41,2 31,2 20,0 12,5 10 1000
65134 25x63~400 5 17,3 34,5 11,0 43,5 32,5 25,0 18,5 10 500
65136 32x75~400 5 21,8 43,5 12,0 51,0 39,0 32,0 31,0 5 400
65138 40x90~400 5 26,8 53,5 14,0 56,0 42,0 40,0 73,0 5 200

INNESTO DIRETTO FILETTATO FEMMINA saldatura a bicchiere

THREADED DIRECT JOINT FEMALE socket welding
Articolo Peso

Item DN /OD SDR A B C D F G Weight

mm mm mm mm mm mm g pezzi pezzi
pieces pieces
65152 F½”x50~400 5 18,5 37,0 10,0 47,0 37,0 20,0 33,0 5 200
65154 F¾”x50~400 5 22,0 44,0 11,0 49,0 38,0 25,0 44,0 5 150

INNESTO DIRETTO FUSIO-TECHNIK A DERIVAZIONE SAFETY saldatura a bicchiere
FUSIO-TECHNIK DIRECT JOINT WITH SAFETY DERIVATION socket welding
Articolo Peso

Item DN /OD SDR A B C D F G Weight

mm mm mm mm mm mm g pezzi pezzi
pieces pieces
65170 sm16x50~400 5 18,5 37,0 10,0 75,0 37,0 20,0 113,0 5 150
65172 sm20x50~400 5 18,5 37,0 10,0 76,2 37,0 20,0 143,0 5
65174 sm26x63~400 5 22,0 44,0 11,0 80,5 38,0 25,0 212,0 5
sm = Connessione maschio safety Connection male safety
