32 SISTEMI DI RACCORDI A PRESSARE
Press Fitting Systems • Pressfittingsysteme • Systèmes de raccords a sertir • Sistema de accesorios para prensar

≤54 B 10 11
181/300
76÷108 B 10 12
CURVA 30° FF
• 30° ELBOW FF
• BOGEN 30° II
• COUDE FF 30°
• CURVA 30° HH
MATERIAL: AISI 316L – 1.4404
O-RING: EPDM nero - black - Schwarz - noir -
negro

De
Z
L
CODE mm mm mm g €
181015300 15 33 13 50 20 300 17,50
181018300 18 32 12 52 20 300 19,36
181022300 22 37 16 82 20 100 22,47
181028300 28 41 18 112 10 100 27,07
181035300 35 37 11 123 10 60 32,39
181042300 42 44 14 175 4 40 46,76
181054300 54 52 17 268 2 20 60,05
181076300 76,1 100 45 900 2 2 223,95
181088300 88,9 115 64 1250 2 2 266,84
181108300 108 127 68 1700 2 2 363,83

≤54 B 10 11
181/301
76÷108 B 10 12
CURVA 30° MF
• 30° ELBOW MF
• BOGEN 30° IA
• COUDE MF 30°
• CURVA 30° HM
MATERIAL: AISI 316L – 1.4404
O-RING: EPDM nero - black - Schwarz - noir -
negro

Z
L
De
H
CODE mm mm mm mm g €
181015301 15 33 43 13 50 20 300 17,50
181022301 22 37 46 16 82 20 100 21,21
181028301 28 41 48 18 112 10 100 25,23
181035301 35 37 46 11 133 10 60 30,17
181042301 42 44 54 14 195 4 40 45,03
181054301 54 52 63 17 293 2 20 57,74
181076301 76,1 100 108 45 900 2 2 205,48
181088301 88,9 115 123 64 1250 2 2 245,29
181108301 108 127 136 68 1700 2 2 334,98

1/2025
