MANOMETRI/PRESSURE GAUGES CAPITOLO 1/CHAPTER 1

M1-40
Cassa in acciaio verniciato nero a secco DN40 Attacco radiale.
Dry black steel case powder coated DN40 bottom entry.
Imballo/ Min.
Codice Scala Attacco Opzioni €/cad
Conf. ord.
Pressure Min.
Part No. Connection Options Box/Master
Range order
0-1.6 bar G1/8B 240/240 240 10,90
0-2.5 bar G1/8B 240/240 240 7,80
PA150423 0-4 bar G1/8B 240/240 240 7,80
PA150623 0-6 bar G1/8B 240/240 240 7,80
PA151023 0-10 bar G1/8B 240/240 240 7,80
PA151623 0-16 bar G1/8B 240/240 240 7,80
0-20 bar G1/8B 240/240 240 7,80
PA152523 0-25 bar G1/8B 240/240 240 7,80
PA154023 0-40 bar G1/8B 240/240 240 7,80
0-60 bar G1/8B 240/240 240 11,60
0-100 bar G1/8B 240/240 240 11,60
0-160 bar G1/8B 240/240 240 11,60
0-250 bar G1/8B 240/240 240 11,60
0-315 bar G1/8B 240/240 240 11,60
0-400 bar G1/8B 240/240 240 11,60

Legenda opzioni vedere pag.83/Options legend see pag.83

M1-50

Cassa in acciaio verniciato nero a secco DN50 attacco radiale.
Dry black steel case powder coated DN50 bottom entry.

Imballo/ Min.
Codice Scala Attacco Opzioni €/cad
Conf. ord.
Pressure Min.
Part No. Connection Options Box/Master
Range order
PA2401BJ00 -1/0 bar G1/4B 100/100 100 12,50
PA240122 0-1 bar G1/4B 100/100 100 11,50
0-1.6 bar G1/4B 100/100 100 11,60
0-2.5 bar G1/4B 100/100 100 8,20
0-4 bar G1/4B 100/100 100 8,20
PA250624 0-6 bar/psi G1/4B D+C 100/100 100 8,10
PA251024 0-10 bar/psi G1/4B D+C 100/100 100 8,10
PA251624 0-16 bar/psi G1/4B D+C 100/100 100 8,10
0-20 bar G1/4B 100/100 100 8,10
0-25 bar G1/4B 100/100 100 8,10
0-40 bar G1/4B 100/100 100 8,10
0-60 bar G1/4B 100/100 100 12,60
PA264822 0-100 bar/psi G1/4B D+C 100/100 100 12,60
0-160 bar G1/4B 100/100 100 12,60
0-250 bar G1/4B 100/100 100 12,60
PA266214 0-315 bar/psi G1/4B D+C 100/100 100 12,60
0-400 bar G1/4B 100/100 100 12,60
Legenda opzioni vedere pag.83/Options legend see pag.83
