RACCORDI IN ACCIAIO INOX

RACCORDI INOX A SALDARE - MISURE ISO

CURVE 90° RICAVATE DA TUBO SALDATO

AISI 304L AISI 316L
DIMA 3 DIMA 3 DIMA 5 **
Ø Ø mm DN € € € € €
COD. SPESS. COD. SPESS. COD. SPESS. COD. SPESS. COD. SPESS.
2 mm 3 mm 2 mm 3 mm 2 mm
3/8” 17,2 10 IC934202 * IC936202 *
1/2” 21,3 15 IC934203 4,25 IC936203 5,20 IC956203 *
3/4” 26,9 20 IC934204 4,40 IC936204 5,65 IC956204 *
1” 33,7 25 IC934205 4,85 IC934305 7,75 IC936205 6,25 IC936305 9,55 IC956205 *
1 1/4” 42,4 32 IC934206 6,25 IC934306 9,85 IC936206 7,90 IC936306 12,30 IC956206 *
1 1/2” 48,3 40 IC934207 7,15 IC934307 9,70 IC936207 9,25 IC936307 13,35 IC956207 *
2” 60,3 50 IC934208 10,00 IC934308 13,80 IC936208 13,50 IC936308 17,75 IC956208 *
2 1/2” 76,1 65 IC934209 16,10 IC934309 20,65 IC936209 19,70 IC936309 29,70 IC956209 *
3” 88,9 80 IC93420A 21,40 IC93430A 29,85 IC93620A 29,40 IC93630A 40,80 IC95620A *
3 1/2” 101,6 90 IC93420B 31,70 IC93430B 42,00 IC93620B 36,40 IC93630B 58,50
4” 114,3 100 IC93420C 32,30 IC93430C 48,50 IC93620C 46,55 IC93630C 64,70 IC95620C *
5” 139,7 125 IC93420D 71,55 IC93430D 106,85 IC93620D 102,30 IC93630D 128,05 IC95620D *
6” 168,3 150 IC93420E 97,60 IC93430E 133,95 IC93620E 147,30 IC93630E 198,35 IC95620E *
8” 219,1 200 IC93420F 175,80 IC93430F 260,00 IC93620F 236,10 IC93630F 358,50 IC95620F *
10” 273,0 250 IC93420G 371,85 IC93430G 473,35 IC93620G 421,25 IC93630G 632,90
12” 323,9 300 IC93420H * IC93430H * IC93620H * IC93630H *
14” 355,6 350 IC93430I *
16” 406,4 400 IC93430L *
Dalla misura 17,2 mm. alla 60,3 mm. si forniscono a multipli di 5 unità.
** Su richiesta disponibili in AISI 304L e/o in spessori differenti.

CURVE 45°
RICAVATE DA TUBO SALDATO

AISI 316L
DIMA 3
Ø Ø mm DN € €
COD. SPESS. COD. SPESS.
2 mm 3 mm
3/8” 17,2 10 IC436202 *
1/2” 21,3 15 IC436203 *
3/4” 26,9 20 IC436204 *
1” 33,7 25 IC436205 * IC436305 *
1 1/4” 42,4 32 IC436206 * IC436306 *
1 1/2” 48,3 40 IC436207 * IC436307 *
2” 60,3 50 IC436208 * IC436308 *
2 1/2” 76,1 65 IC436209 * IC436309 *
3” 88,9 80 IC43620A * IC43630A *
3 1/2” 101,6 90 IC43620B * IC43630B *
4” 114,3 100 IC43620C * IC43630C *
5” 139,7 125 IC43620D * IC43630D *
6” 168,3 150 IC43620E * IC43630E *
8” 219,1 200 IC43620F * IC43630F *
Disponibili anche a 30° e 60° su richiesta.
* Prezzo a richiesta
