RACCORDI INOX A SALDARE - MISURE MILIMETRICHE

CURVE 90º 3D RICAVATE DA TUBO SALDATO

Ø Ø mm. DN R mm. SPESS. AISI 304L AISI 316L
mm.
COD. E COD. E
1/2” 18,0 15 25,0 1,5 IC341018 3,80 IC361018 3,55
1/2” 20,0 15 30,0 1,5 IC341020 3,90 IC361020 3,65
3/4” 23,0 20 35,0 1,5 IC341023 3,95
3/4” 25,0 20 37,0 1,5 IC341025 4,00 IC361025 5,30
3/4” 28,0 20 40,0 1,5 IC341028 4,10 IC361028 5,50
3/4” 30,0 20 45,0 1,5 IC341030 4,40 IC361030 5,60
1” 33,0 25 50,0 1,5 IC341033 4,70 IC361033 5,70
1 1/4” 35,0 32 52,5 1,5 IC341035 5,05
1 1/4” 38,0 32 55,0 1,5 IC341038 5,30
1 1/2” 40,0 40 60,0 1,5 IC341040 5,60 IC361040 7,40
1 1/2” 43,0 40 65,0 1,5 IC341043 6,50 IC361043 7,45
2” 50,8 50 76,0 1,5 IC341051 7,60 IC361050 9,95
2” 53,0 50 80,0 1,5 IC341053 8,05 IC361053 10,50
2” 63,5 50 95,0 1,5 IC341063 11,20 IC361063 13,65
2” 54,0 50 80,0 2,0 IC342054 15,40
2” 57,0 50 85,5 2,0 IC342057 15,05 RACCORDI IN ACCIAIO INOX
2 1/2” 70,0 65 92,0 2,0 IC342070 9,00 IC362070 22,35
2 1/2” 73,0 65 110,0 1,5 IC341073 10,65 IC361073 22,50
2 1/2” 76,0 65 115,0 1,5 IC341076 13,60 IC361076 15,30
3” 84,0 80 125,0 2,0 IC342084 20,35 IC362084 25,45
4” 104,0 100 155,0 2,0 IC342104 27,75 IC362104 39,00
5” 129,0 125 190,0 2,0 IC342129 59,55 IC362129 75,60
6” 154,0 150 225,0 2,0 IC342154 78,35 IC362154 85,85
8” 204,0 200 300,0 2,0 IC342204 120,10 IC362204 170,30
10” 254,0 250 380,0 2,0 IC342254 274,70

TI FONDI BOMBATI

SPESS. AISI 304L AISI 316L SPESS. AISI 304L AISI 316L
Ø mm. DN Ø mm. DN
mm. COD. E COD. E mm. COD. E COD. E
25,0 20 1,5 ITM41025 13,75 ITM61025 15,80 25,0 20 1,5 ICAM4025 2,55 ICAM6025 3,55
28,0 20 1,5 ITM41028 13,75 ITM61028 16,10 28,0 20 1,5 ICAM4028 2,75 ICAM6028 3,75
33,0 25 1,5 ITM41033 15,25 ITM61033 18,50 33,0 25 1,5 ICAM4033 2,95 ICAM6033 3,90
43,0 40 1,5 ITM41043 20,55 ITM61043 21,95 43,0 40 1,5 ICAM4043 3,70 ICAM6043 5,30
50,8 50 1,5 ITM41050 22,30 ITM61050 24,20 50,8 50 1,5 ICAM4050 4,50 ICAM6050 6,25
53,0 50 1,5 ITM41053 22,30 ITM61053 27,35 53,0 50 1,5 ICAM4053 4,60 ICAM6053 6,65
63,5 50 1,5 ITM41063 34,50 ITM61063 39,80 63,5 50 1,5 ICAM4063 5,90 ICAM6063 8,75
73,0 65 1,5 ITM41073 43,00 ITM61073 49,20 70,0 65 2,0 ICAM4070 6,35 ICAM6070 8,90
84,0 80 2,0 ITM42084 44,90 ITM62084 60,50 73,0 65 1,5 ICAM4073 6,60 ICAM6073 9,90
104,0 100 2,0 ITM42104 63,50 ITM62104 85,35 84,0 80 2,0 ICAM4084 7,75 ICAM6084 10,90
129,0 125 2,0 ITM42129 128,25 ITM62129 155,00 104,0 100 2,0 ICAM4104 11,30 ICAM6104 13,55
154,0 150 2,0 ITM42154 175,25 ITM62154 219,35 129,0 125 2,0 ICAM4129 14,55 ICAM6129 19,60
204,0 200 2,0 ITM42204 312,05 ITM62204 379,90 154,0 150 2,0 ICAM4154 22,55 ICAM6154 27,50
254,0 250 2,0 ITM42254 598,15 ITM62254 740,20 204,0 200 2,0 ICAM4204 34,45 ICAM6204 47,15
304,0 300 2,0 ITM62304 1.124,85 254,0 250 2,0 ICAM4254 49,85 ICAM6254 72,10
354,0 300 2,0 ITM62354 1.525,95 304,0 300 2,0 ICAM4304 73,15 ICAM6304 93,00
354,0 300 2,0 ICAM4354 125,15 ICAM6354 167,25
