RACCORDI A SALDARE - NORMA ASTM - SCH. 10S
RICAVATI DA TUBO SALDATO

CURVE LR 90º TI

AISI 316L
AISI 304L
AISI 316L
AISI 304L
Ø Ø EXT SPESS. COD. E COD. E Ø Ø EXT SPESS. COD. E COD. E
mm.
mm.
mm.
mm.
1/2" 21,3 2,11 I1CL940M 3,90 I1CL960M 4,75 1/2" 21,3 2,11 I1T4000M 9,25 I1T6000M 12,40
3/4" 26,7 2,11 I1CL940T 5,00 I1CL960T 6,20 3/4" 26,7 2,11 I1T4000T 9,75 I1T6000T 12,70
1" 33,4 2,77 I1CL9401 5,40 I1CL9601 6,75 1" 33,4 2.77 I1T40001 10,30 I1T60001 12,90
1 1/4" 42,2 2,77 I1CL941C 6,55 I1CL961C 8,05 1 1/4" 42,2 2.77 I1T4001C 14,05 I1T6001C 17,60
1 1/2" 48,3 2,77 I1CL941M 9,30 I1CL961M 11,55 1 1/2" 48,3 2.77 I1T4001M 20,35 I1T6001M 25,30
2" 60,3 2,77 I1CL9402 12,35 I1CL9602 15,60 2" 60,3 2.77 I1T40002 24,15 I1T60002 30,05
2 1/2" 73,0 3,05 I1CL942M 17,50 I1CL962M 21,90 2 1/2" 73,0 3,05 I1T4002M 41,75 I1T6002M 51,60
3" 88,9 3,05 I1CL9403 27,20 I1CL9603 35,35 3" 88,9 3,05 I1T40003 48,75 I1T60003 61,25
4" 114,3 3,05 I1CL9404 47,05 I1CL9604 60,35 4" 114,3 3,05 I1T40004 78,95 I1T60004 98,00
5" 141,3 3,40 I1CL9405 87,10 I1CL9605 112,05 5" 141,3 3,40 I1T40005 142,70 I1T60005 174,15
6" 168,3 3,40 I1CL9406 120,80 I1CL9606 155,65 6" 168,3 3,40 I1T40006 176,80 I1T60006 219,20
8" 219,1 3,76 I1CL9408 217,65 I1CL9608 276,30 8" 219,1 3,76 I1T40008 394,90 I1T60008 484,95
RACCORDI IN ACCIAIO INOX
10" 273,0 4,19 I1CL9410 469,50 I1CL9610 601,75

FONDI BOMBATI STUB END

AISI 316L
AISI 304L
AISI 316L
AISI 304L
Ø Ø EXT SPESS. COD. E COD. E Ø Ø EXT SPESS. COD. E COD. E
mm.
mm.
mm.
mm.
1/2" 21,3 2,11 I1CC400M 4,45 I1CC600M 6,20 1/2" 21,3 2,11 I1SE400M 9,70 I1SE600M 13,85
3/4" 26,7 2,11 I1CC400T 5,35 I1CC600T 7,45 3/4" 26,7 2,11 I1SE400T 10,40 I1SE600T 14,85
1" 33,4 2,77 I1CC4001 6,65 I1CC6001 9,20 1" 33,4 2,77 I1SE4001 12,55 I1SE6001 15,95
1 1/4" 42,2 2,77 I1CC401C 7,55 I1CC601C 10,60 1 1/4" 42,2 2,77 I1SE401C 13,35 I1SE601C 18,15
1 1/2" 48,3 2,77 I1CC401M 8,45 I1CC601M 12,05 1 1/2" 48,3 2,77 I1SE401M 14,55 I1SE601M 20,35
2" 60,3 2,77 I1CC4002 8,80 I1CC6002 12,50 2" 60,3 2,77 I1SE4002 21,10 I1SE6002 29,40
2 1/2" 73,0 3,05 I1CC402M 11,85 I1CC602M 16,25 2 1/2" 73,0 3,05 I1SE402M 23,40 I1SE602M 32,15
3" 88,9 3,05 I1CC4003 17,75 I1CC6003 24,40 3" 88,9 3,05 I1SE4003 31,55 I1SE6003 43,45
4" 114,3 3,05 I1CC4004 25,95 I1CC6004 36,90 4" 114,3 3,05 I1SE4004 47,15 I1SE6004 64,45
5" 141,3 3,40 I1CC4005 43,60 I1CC6005 61,20 5" 141,3 3,40 I1SE4005 68,00 I1SE6005 94,85
6" 168,3 3,40 I1CC4006 54,50 I1CC6006 77,35 6" 168,3 3,40 I1SE4006 104,75 I1SE6006 142,70
8" 219,1 3,76 I1CC4008 88,55 I1CC6008 129,45 8" 219,1 3,76 I1SE4008 170,65 I1SE6008 242,20
10" 273,0 4,19 I1SE4010 337,65 I1SE6010 472,65
