d Wmax U V V1 Lg D2 k Y1 Y M2 E H4 Q1
(mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm)
* 355 535,0 180 410,0 268,0 129 535 460 209,0 195,0 153,0 100 325
* 400 595,0 180 435,0 300,0 169 595 515 234,0 326,0 176,0 100 353
* 450 635,0 220 520,0 320,0 179 635 565 234,0 326,0 176,0 130 393
* 500 700,0 220 550,0 350,0 190 700 620 270,0 263,0 206,0 130 444
* 630 813,0 220 610,0 420,0 209 813 725 270,0 263,0 206,0 130 530
d Hmax Q2 Lmax
(mm) (mm) (mm) (mm)
63 325,3 274,4
75 338,2 35 274,4
90 362,9 50 325,2
110 386,9 74 359,6
140 448,3 97 418,0
160 473,0 123 434,0
225 528,8 169 498,4
280 676,9 207 646,0
315 741,4 253 681,0
* 355 887,0 305 390,0
* 400 972,0 350 458,0
* 450 1077,0 390 458,0
* 500 1173,0 440 525,0
* 630 1303,0 527 525,0
