Page 229 - DAB PUMPS - LISTINO 50_2025

RAGGRUPPAMENTO: BC
ELETTROPOMPE CENTRIFUGHE NORMALIZZATE - KDN

TABELLE DI SELEZIONE SERVIZI DAB

4 POLI = 1450 1/min
3
Q (m /c) 0 3 6 12 18 24 30 36
MODELLO
(l/min) 0 50 100 200 300 400 500 600
KDN 32-125.1/105 3.5 3.4 3.1
KDN 32-125.1/110 3.9 3.8 3.5 RISCALDAMENTO E RISCALDAMENTO E CONDIZIONAMENTO
KDN 32-125.1/115 4.25 4.2 3.9
KDN 32-125.1/120 4.7 4.6 4.3
KDN 32-125.1/125 5.1 5.1 4.8
KDN 32-125.1/130 5.6 5.6 5.3
KDN 32-125.1/135 6.1 6 5.8 4.4
KDN 32-125.1/140 6.6 6.6 6.4 5.1
KDN 32-125/115 4.3 4.1 3.2
KDN 32-125/120 4.75 4.6 3.75 ESYBOX LINE ESYBOX LINE
KDN 32-125/125 5.2 5.05 4.2
KDN 32-125/130 5.7 5.5 4.8
KDN 32-125/135 6.2 6 5.3 3.65
KDN 32-125/142 6.9 6.75 6.15 4.5
KDN 32-160.1/137 5.3 5.3 4.7
KDN 32-160.1/145 6.2 6.1 5 UNITÀ DI CONTROLLO UNITÀ DI CONTROLLO
KDN 32-160.1/153 7 7 6.6
KDN 32-160.1/161 8 7.9 7.6
KDN 32-160.1/169 8.9 8.9 8.6 5.5
KDN 32-160.1/177 9 9.8 9.5 6.6
KDN 32-160/137 5.9 5.6 4.4
KDN 32-160/145 6.7 6.5 5.3
KDN 32-160/153 7.6 7.4 6.25
KDN 32-160/161 8.5 8.25 7.25 8.7 AUMENTO PRESSIONE AUMENTO PRESSIONE
KDN 32-160/169 9.5 9.3 8.4 6.6
KDN 32-160/177 10.5 10.4 9.6 7.8
KDN 32-200.1/170 8.6 8.5 7.2
KDN 32-200.1/180 9.8 9.8 9
KDN 32-200.1/190 11.3 11.1 10.5
KDN 32-200.1/200 H (m) 12.8 12.7 11.7 8.3
KDN 32-200.1/207 13.8 13.8 13 8.9 PRESSURIZZAZIONE
KDN 32-200/170 8.6 8.2 6.7 GRUPPI DI GRUPPI DI
KDN 32-200/180 9.9 9.6 8.2
KDN 32-200/190 11.2 10.9 9.7 7
KDN 32-200/200 12.6 12.3 11.1 8.7
KDN 32-200/210 14.3 14 13.1 10.7
KDN 32-200/219 15.7 15.4 14.8 13 9.8
KDN 40-125/115 4.2 4.1 3.8 3.2 2.4 NORMALIZZATE E VERTICALI
KDN 40-125/120 4.6 4.5 4.2 3.7 2.9 MONOBLOCCO MONOBLOCCO
KDN 40-125/125 5.1 4.9 4.7 4.1 3.3
KDN 40-125/130 5.5 5.4 5.2 4.7 3.9
KDN 40-125/135 6 5.9 5.8 5.3 4.6
KDN 40-125/142 6.7 6.6 6.5 6 5.3 4.1
KDN 40-160/137 5.9 5.8 5.8 5 3.7
KDN 40-160/145 6.7 6.6 6.5 6 4.8
KDN 40-160/153 7.6 7.6 7.5 7 6.8 DRENAGGIO E FOGNATURA
KDN 40-160/161 8.6 8.5 8.4 8 7.1 5.6 DRENAGGIO
KDN 40-160/169 9.6 9.5 9.5 9.1 8.3 7
KDN 40-160/177 10.7 10.7 10.6 10.2 9.5 8.3
KDN 40-200/170 8.4 8.4 8.2 7.4 5.7
KDN 40-200/180 9.7 9.7 9.4 8.8 7.2
KDN 40-200/190 10.9 10.8 10.7 10.2 8.8 6.8 SOTTOSUOLO E IRRIGAZIONE
KDN 40-200/200 12.2 12.1 12 11.7 10.4 8.6
KDN 40-200/210 13.6 13.5 13.5 13.2 12.1 10.6 PRELIEVO DAL PRELIEVO DAL
KDN 40-200/219 15 15 15 14.7 13.8 12.4 10.4
KDN 40-250/220 15.8 15.6 14.8 13.6 12
KDN 40-250/230 17.4 17.2 16.5 15.3 13.7
KDN 40-250/240 19.1 19 18.2 17 15.5
POMPE PER PISCINE POMPE PER PISCINE
KDN 40-250/250 20.7 20.6 20 18.9 17.5
KDN 40-250/260 22.7 22.6 22.1 21 19.5
