SISTEMI DI RACCORDI A PRESSARE 275
Press Fitting Systems • Pressfittingsysteme • Systèmes de raccords a sertir • Sistema de accesorios para prensar

B 70 78
697/B GU
GOMITO MISTO 90° FILETTO M
• ELBOW ADAPTER 90° WITH MALE THREAD
• ÜBERGANGSWINKEL 90° AG
• EQUERRE 90° AVEC FILETAGE M
• CODO MACHO
MATERIAL: CuZn21Si3P - CW724R
O-RING: HNBR giallo - yellow - Gelb - jaune -
amarillo
THREAD: EN 10226-1 (ex ISO 7/1)

L1
De x R
Y
Z
L2
CODE mm x inch mm mm mm mm g €
697102015BGU 15 x 1/2” 35 39 17 24 106 5* 150 34,12
697102018BGU 18 x 1/2” 42 42 20 24 130 5* 120 54,12
697304018BGU 18 x 3/4” 41 46 24 30 163 5* 100 52,92
697304022BGU 22 x 3/4” 41 44 21 30 182 5* 80 55,09
697100028BGU 28 x 1” 58 58 34 36 378 2* 50 82,39
697114035BGU 35 x 1”1/4 58 58 32 45 465 2* 40 109,54
697112042BGU 42 x 1”1/2 65 65 29 50 582 1* 24 149,52
697200054BGU 54 x 2” 80 83 42 65 1173 1* 16 211,58
(*) unità minima di vendita / minimum selling quantity
