DN Range 1 Flange 3 Drilling NBR / A2 EUR Peso
(mm) (mm) (mm) pattern Codice (kg)
700 709 ‐ 741 700 PN10/PN16 On Request
800 799 ‐ 831 800 PN10/PN16 On Request
900 899 ‐ 931 900 PN10/PN16 On Request
1000 899 ‐ 931 1000 PN10/PN16 On Request

DN NBR / A4 EUR
(mm) Codice
50
65
80
100
125
150
200
250
300
350
400
450
500
600
700 709 355 282 On Request
800 709 355 283 On Request
900 709 355 301 On Request
1000 709 355 302 On Request

DN a b ID min. e PN Acqua MOP Gas No. of
(mm) (mm) (mm) (mm) (mm) (bar) (bar) bolt holes
flange
50 165 ‐ 187 170 84 3xM12 16 8 4
65 170 ‐ 193 191 84 3xM12 16 8 4
80 170 ‐ 192 210 84 3xM12 16 8 8
100 173 ‐ 199 241 90 3xM16 16 8 8
125 192 ‐ 215 270 90 4xM16 16 8 8
150 211 ‐ 248 312 110 4xM16 16 8 8
200 221 ‐ 258 371 110 6xM16 16 8 8/12
250 264 ‐ 307 445 130 6xM20 16 8 12
300 293 ‐ 331 495 130 8xM20 16 8 12
350 291 ‐ 336 534 130 8xM20 16* 8* 16
400 297 ‐ 342 580 135 10xM20 16* 8* 16
450 330 ‐ 367 641 160 10xM20 10 5 20
500 332 ‐ 369 715 160 10xM20 10 5 20
600 339 ‐ 377 840 170 14xM20 10 5 20
700 434 ‐ 464 940 210 16xM20 10 - 24
800 431 ‐ 461 1030 210 20xM20 10 - 24
900 474 ‐ 504 1130 210 22xM20 10 - 28
1000 474 ‐ 504 1255 210 24xM20 10 - 28
