RACCORDI IN ACCIAIO INOX

RACCORDI FILETTATI AISI 316

90 GOMITO F/F 92 GOMITO M/F

ISO 4144 PN 10 ISO 4144 PN 10
Ø E E Ø E E
COD. COD. COD. COD.
1/8 ” 400 10 I0906000 3,48 1/8” 500 10 I0926000 4,10
1/4” 400 10 I0906001 3,20 1/4” 350 10 I0926001 4,10
3/8” 290 10 I0906002 3,31 3/8” 260 10 I0926002 4,21
1/2” 160 10 I0906003 3,82 I090L003 3,22 1/2” 160 10 I0926003 4,72 I092L003 3,26
3/4” 80 10 I0906004 5,67 I090L004 4,57 3/4” 100 10 I0926004 7,02 I092L004 4,69
1” 50 10 I0906005 9,55 I090L005 8,36 1” 50 10 I0926005 10,90 I092L005 7,27
1 1/4” 24 4 I0906006 14,21 I090L006 13,47 1 1/4” 25 5 I0926006 17,30 I092L006 14,72
1 1/2” 18 2 I0906007 21,40 I090L007 15,58 1 1/2” 18 2 I0926007 21,90 I092L007 17,92
2” 10 1 I0906008 29,48 I090L008 23,75 2” 10 1 I0926008 31,96 I092L008 21,68
2 1/2” 6 1 I0906009 60,48 2 1/2” 4 1 I0926009 72,28
3” 3 1 I090600A 83,29 3” 3 1 I092600A 105,81
4” 1 I090600C 142,42 4” 1 I092600C 177,41
3/4” x 1/2” 90 10 I090L043 5,16
1" x 3/4” 50 10 I090L054 7,27
1 1/4” x 3/4" 30 10 I090L064 11,35
1 1/4” x 1" 30 10 I090L065 14,02

ISO
BOCCHETTONE CONICO 4144 BOCCHETTONE CONICO
96 CURVO F/F 98 CURVO M/F

Ø COD. E Ø COD. E

1/2” 50 5 I0966003 22,58 1/2” 50 5 I0986003 23,42
3/4” 40 5 I0966004 27,35 3/4” 30 5 I0986004 30,44
1” 20 2 I0966005 35,10 1” 14 2 I0986005 38,41
1 1/4” 15 1 I0966006 58,07 1 1/4” 12 1 I0986006 65,48
1 1/2” 12 1 I0966007 68,57 1 1/2” 8 1 I0986007 95,30
2” 6 1 I0966008 96,43 2” 6 1 I0986008 112,38

ISO
120 GOMITO 45° F/F 4144 121 GOMITO 45° M/F

Ø COD. E Ø COD. E
1/4” 400 10 I1206001 4,38 1/4” 400 10 I1216001 3,20
3/8” 300 10 I1206002 5,00 3/8” 200 10 I1216002 4,44
1/2” 150 5 I1206003 5,17 1/2” 150 5 I1216003 5,95
3/4” 90 5 I1206004 7,97 3/4” 90 5 I1216004 8,31
1” 60 5 I1206005 10,78 1” 60 5 I1216005 14,77
1 1/4” 30 1 I1206006 15,89 1 1/4” 30 1 I1216006 21,23
1 1/2” 20 1 I1206007 21,51 1 1/2” 20 1 I1216007 24,94
2” 12 1 I1206008 32,29 2” 12 1 I1216008 38,30
2 1/2” 8 1 I1206009 71,77 2 1/2” 8 1 I1216009 79,47
3” 4 1 I120600A 86,60 3” 4 1 I121600A 101,09
