Page 59 - ATUSA - LISTINO 2023

PIANA (TIPO 01) - MATERIALE P245GH PIANA (TIPO 01) - MATERIALE P245GH
DIMENSIONI ACCIAIO AL CARBONIO
PN 6 PN 10 PN 16 PN 25 PN 40 RACCORDI IN
DN “ mm. COD. € COD. € COD. € COD. DIN € COD. DIN €
15 1/2" 21,3 FC010015 4,30 FC014015 6,40 FC014015 6,40 FC014015 6,40 FC014015 6,40
20 3/4" 26,9 FC010020 4,75 FC014020 7,25 FC014020 7,25 FC014020 7,25 FC014020 7,25
25 1" 33,7 FC010025 5,40 FC014025 7,50 FC014025 7,50 FC014025 7,50 FC014025 7,50
32 11/4" 42,4 FC010032 8,85 FC014032 11,90 FC014032 11,90 FC014032 11,90 FC014032 11,90
40 11/2" 48,3 FC010040 10,00 FC014040 14,55 FC014040 14,55 FC014040 14,55 FC014040 14,55
50 2" 60,3 FC010050 10,85 FC016050 17,30 FC016050 17,30 FC016050 17,30 FC016050 17,30
21/2" 76,1 F2576065 20,70 F2576065 20,70
65
21/2" 76,1 FC010065 13,60 FC016065 20,70 FC016065 20,70 FC014065 34,10 FC014065 34,10
3" 88,9 FC010080 21,50 F2576080 23,40 FC016080 23,40 FC014080 46,05 FC014080 46,05
80
FC016080 23,40
90 31/2" 101,6 F2576101 27,35
4" 108,0 F2576108 27,35
100
4" 114,3 FC010100 23,80 FC016100 27,35 FC016100 27,35 FC014100 61,10 FC014100 61,10
5" 133,0 F2576133 34,65
125
5" 139,7 FC010125 29,95 FC016125 34,65 FC016125 34,65 FC014125 83,30 FC014125 83,30
6" 159,0 F2576159 45,60
150
6" 168,3 FC010150 33,05 FC016150 45,60 FC016150 45,60 FC014150 106,90 FC014150 106,90
175 7" 193,7 F2576175 57,80
200 8" 219,1 FC010200 47,80 FC011200 57,80 FC016200 61,85 FC012200 143,85 FC014200 179,70
250 10" 273,0 FC010250 63,05 FC011250 79,45 FC016250 95,80 FC012250 205,15 FC014250 285,10
300 12" 323,9 FC010300 84,25 FC011300 89,40 FC016300 130,55 FC012300 264,35 FC014300 390,25
350 14" 355,6 FC010350 123,90 FC011350 141,45 FC016350 199,05 FC012350 509,90 FC014350 707,35
400 16" 406,4 FC010400 148,85 FC011400 208,40 FC016400 258,05 FC012400 545,70 FC014400 841,15
450 18" 457,0 FC010450 198,50 FC011450 241,90 FC016450 319,05
500 20" 508,0 FC010500 308,00 FC011500 283,85 FC016500 443,05 FC012500 818,05 FC014500 985,30
24" 610,0 FC011600 414,10 FC016600 740,75
600
24" 610,0 F2576600 * F2502600 *
700 28" 711,0 F2576700 * F2502700 *
800 32" 813,0 F2576800 * F2502800 *
900 36" 914,0 F2576900 * F2502900 *
1000 40" 1.016,0 F2576999 * F2502999 *

* A richiesta

59
