RACCORDI IN ACCIAIO AL CARBONIO

RACCORDI IN ACCIAIO A SALDARE NORMA ASME
CURVE ASTM A-234 WPB - ASME B 16.9

SCH. 20 STD XS
DIMENSIONI RAIO LONGO LONG RADIUS SHORT RADIUS LONG RADIUS SHORT RADIUS
90º 90º 45º 180º 90º 90º 45º 90º
Ø EXT.
Ø COD. € COD. € COD. € COD. € COD. € COD. € COD. € COD. €
mm.
1/2” 21,3 CSTL900M 3,79 CSTL450M 3,33 CXSL900M 6,60 CXSL450M 6,60
3/4” 26,7 CSTL900T 3,92 CSTL450T 3,40 CXSL900T 6,73 CXSL450T 6,73
1” 33,4 CSTL9001 4,38 CSTL4501 3,66 CSTS9001 11,96 CXSL9001 6,86 CXSL4501 6,86 CXSS9001 17,18
1 1/4” 42,2 CSTL901C 4,97 CSTL451C 4,12 CSTS901C 12,61 CXSL901C 7,91 CXSL451C 7,91 CXSS901C 19,73
1 1/2” 48,3 CSTL901M 5,75 CSTL451M 4,90 CSTL181M 15,29 CSTS901M 12,81 CXSL901M 9,08 CXSL451M 9,08 CXSS901M 20,19
2” 60,3 CSTL9002 7,25 CSTL4502 6,34 CSTL1802 34,70 CSTS9002 14,11 CXSL9002 11,89 CXSL4502 11,89 CXSS9002 21,89
2 1/2” 73,0 CSTL902M 11,70 CSTL452M 9,67 CSTL182M 60,83 CSTS902M 19,28 CXSL902M 20,84 CXSL452M 20,84 CXSS902M 37,05
3” 88,9 CSTL9003 17,25 CSTL4503 14,18 CSTL1803 90,10 CSTS9003 22,41 CXSL9003 28,23 CXSL4503 28,23 CXSS9003 45,48
3 1/2” 101,6 CSTL903M 42,50 CSTL453M 19,60 CXSL903M 42,54 CXSL453M 40,12
4” 114,3 CSTL9004 27,90 CSTL4504 22,74 CSTL1804 143,88 CSTS9004 40,12 CXSL9004 46,33 CXSL4504 39,99 CXSS9004 65,67
5” 141,3 CSTL9005 51,00 CSTL4505 40,31 CSTL1805 245,42 CSTS9005 73,83 CXSL9005 83,44 CXSL4505 74,81 CXSS9005 154,40
6” 168,3 CSTL9006 72,50 CSTL4506 59,79 CSTL1806 419,48 CSTS9006 90,10 CXSL9006 127,94 CXSL4506 109,77 CXSS9006 186,74
8” 219,1 C2TL9008 144,80 CSTL9008 135,00 CSTL4508 118,40 CSTS9008 186,15 CXSL9008 260,77 CXSL4508 196,80 CXSS9008 316,31
10” 273,0 C2TL9010 248,85 CSTL9010 280,00 CSTL4510 217,45 CSTS9010 364,14 CXSL9010 417,26 CXSL4510 332,45 CXSS9010 510,89
12” 323,8 C2TL9012 359,45 CSTL9012 355,00 CSTL4512 322,19 CSTS9012 546,18 CXSL9012 594,20 CXSL4512 424,32 CXSS9012 715,54
14” 355,6 CSTL9014 490,00 CSTL4514 440,78 CSTS9014 793,88 CXSL9014 777,68 CXSL4514 516,77 CXSS9014 1.250,48
16” 406,4 CSTL9016 650,00 CSTL4516 559,31 CSTS9016 1.006,24 CXSL9016 1.017,61 CXSL4516 917,96 CXSS9016 1.496,02
18” 457,0 CSTL9018 975,00 CSTL4518 758,47
20” 508,0 CSTL9020 1.190,00 CSTL4520 972,13
24” 610,0 CSTL9024 1.890,00 CSTL4524 1.359,40

FONDI BOMBATI ASTM A-234 WPB - ASME B 16.9 TI ASTM A-234 WPB - ASME B 16.9

DIMENSIONI STD XS STD XS
Ø EXT.
Ø COD. € COD. € COD. € COD. €
mm.
1/2” 21,3 CCSTXX0M 4,90 CCXSXX0M 5,82 CTXXXX21 7,58 CTXSXX0M 10,58
3/4” 26,7 CCSTXX0T 5,03 CCXSXX0T 6,01 CTXXXX27 7,72 CTXSXX0T 10,84
1” 33,4 CCSTXX01 5,49 CCXSXX01 6,21 CTXXXX33 8,98 CTXSXX01 12,51
1 1/4” 42,2 CCSTXX1C 5,82 CCXSXX1C 8,49 CTXXXX42 9,45 CTXSXX1C 15,17
1 1/2” 48,3 CCSTXX1M 6,27 CCXSXX1M 8,82 CTXXXX48 11,98 CTXSXX1M 19,23
2” 60,3 CCSTXX02 6,60 CCXSXX02 8,95 CTXXXX60 15,70 CTXSXX02 31,47
2 1/2” 73,0 CCSTXX2M 8,17 CCXSXX2M 11,37 CTXXXX76 26,94 CTXSXX2M 43,11
3” 88,9 CCSTXX03 9,08 CCXSXX03 13,07 CTXXXX89 34,73 CTXSXX03 55,82
3 1/2” 101,6 CCSTXX3M 21,00 CCXSXX3M 26,50 CTXXX101 61,00 CTXSXX3M 90,50
4” 114,3 CCSTXX04 15,16 CCXSXX04 22,80 CTXXX114 51,00 CTXSXX04 83,16
5” 141,3 CCSTXX05 21,82 CCXSXX05 32,08 CTXXX140 83,00 CTXSXX05 142,50
6” 168,3 CCSTXX06 30,38 CCXSXX06 42,86 CTXXX168 95,00 CTXSXX06 218,61
8” 219,1 CCSTXX08 48,50 CCXSXX08 77,95 CTXXX219 185,00 CTXSXX08 359,65
10” 273,0 CCSTXX10 81,50 CCXSXX10 140,28 CTXXX273 354,00 CTXSXX10 564,16
12” 323,8 CCSTXX12 125,00 CCXSXX12 174,46 CTXXX324 585,00 CTXSXX12 1.276,07
14” 355,6 CCSTXX14 176,00 CCXSXX14 272,66 CTXXX355 1.050,00 CTXSXX14 1.702,85
16” 406,4 CCSTXX16 221,50 CCXSXX16 311,61 CTXXX406 1.480,00 CTXSXX16 2.306,39
18” 457,0 CCSTXX18 275,00 CCXSXX18 449,67 CTXXX457 1.790,00
20” 508,0 CCSTXX20 301,00 CCXSXX20 575,78 CTXXX508 1.890,00
24” 610,0 CCSTXX24 481,00 CCXSXX24 686,40 CTXXX610 3.250,00
