MANOMETRI/PRESSURE GAUGES CAPITOLO 1/CHAPTER 1

M1-ABS 100/R
Cassa in plastica a secco DN100 attacco radiale indice rosso sul trasparente.
Dry plastic case DN100 bottom entry red adjustable pointer on window.
Imballo/
Codice Scala Attacco Opzioni Min.ord. €/cad
Conf.
Pressure
Part No. Connection Options Box/Master Min.order
Range
-1/0 bar G1/2B 1/30 30 25,40
PA5101BD02 0-1 bar G1/2B R+LW 1/30 1 24,10
PA5102BD01 0-1.6 bar G1/2B R+LW 1/30 1 24,10
PA5203BD01 0-2.5 bar G1/2B R+LW 1/30 1 21,40
PA5204BD01 0-4 bar G1/2B R+LW 1/30 1 21,40
PA5206BD03 0-6 bar G1/2B R+LW 1/30 1 21,40
PA5210BD02 0-10 bar G1/2B R+LW 1/30 1 21,40
PA5216BD03 0-16 bar G1/2B R+LW 1/30 1 21,40
PA5225BD02 0-25 bar G1/2B R+LW 1/30 1 21,40
PA5240BD01 0-40 bar G1/2B R+LW 1/30 1 21,40
0-60 bar G1/2B 1/30 30 26,80
0-100 bar G1/2B 1/30 30 26,80
0-160 bar G1/2B 1/30 30 26,80
0-250 bar G1/2B 1/30 30 26,80
0-315 bar G1/2B 1/30 30 26,80
0-400 bar G1/2B 1/30 30 26,80
Legenda opzioni vedere pag.83/Options legend see pag.83

OPZIONI SOGGETTE A LOTTO MINIMO/OPTIONS SUBJECT TO MINIMUM QUANTITY

M1-ABS 50/63 /R+FE: codici PZFEA...

QL Quadranti personalizzati, altre scale e attacchi a richiesta Customized dials, other scale ranges on request

M1-ABS 40/50/63/80/100/R
AT PTFE o-ring solo per filettature cilindriche PTFE sealing ring on parallel threads only

Z Foro di passaggio 0.5 mm Restrictor hole 0.5 mm
Z3 Foro di passaggio 0.35 mm Restrictor hole 0.35 mm

Solo per alte temperature versione in cl.2.5/High temperature version cl.2.5 only

T2 -40°C+90°C -40°C+90°C

QL Quadranti personalizzati, altre scale e attacchi a richiesta Customized dials, other scale ranges on request

M1-ABS 50/63/80/100/R

MS Movimento siliconato per antivibrazione indice Silicone movement for dampened pointer travel

V Indice rosso con settore verde regolabile Adjustable red mark pointer with green sector
