MANOMETRI/PRESSURE GAUGES CAPITOLO 1/CHAPTER 1

OPZIONI SOGGETTE A LOTTO MINIMO/OPTIONS SUBJECT TO MINIMUM QUANTITY
M1-ABS 40/50/63 FE: codici PZFEA...
QL Quadranti personalizzati, altre scale e attacchi a richiesta Customized dials, other scale ranges on request

M1-ABS 40/50/63/80/100
AT PTFE o-ring solo per filettature cilindriche PTFE sealing ring on parallel threads only

Z Foro di passaggio 0.5 mm Restrictor hole 0.5 mm
Z3 Foro di passaggio 0.35 mm Restrictor hole 0.35 mm

Solo per alte temperature versione in cl.2.5/High temperature version cl.2.5 only

T2 -40°C+90°C -40°C+90°C

QL Quadranti personalizzati, altre scale e attacchi a richiesta Customized dials, other scale ranges on request

M1-ABS 50/63/80/100
MS Movimento siliconato per antivibrazione indice Silicone movement for dampened pointer travel

M1-ABS 40/R
Cassa in plastica a secco DN40 attacco radiale indice rosso sul trasparente.
Dry plastic case DN40 bottom entry red adjustable pointer on window.

Imballo/
Codice Scala Attacco Opzioni Min.ord. €/cad
Conf.
Pressure
Part No. Connection Options Box/Master Min.order
Range
0-2.5 bar G1/8B 240/240 240 7,40
PA1204BA02 0-4 bar G1/8B R+QK+LW 240/240 240 7,40
0-6 bar G1/8B 240/240 240 7,40
PA1210BA00 0-10 bar G1/8B R 240/240 240 7,40
0-16 bar G1/8B 240/240 240 7,40
0-25 bar G1/8B 240/240 240 7,40
0-40 bar G1/8B 240/240 240 7,40
Legenda opzioni vedere pag.83/Options legend see pag.83
M1-ABS 50/R - M1-ABS 50/R+FE
Cassa in plastica a secco DN50 attacco radiale indice rosso sul trasparente.
Dry plastic case DN50 bottom entry red adjustable pointer on window.
Imballo/
Codice Scala Attacco Opzioni Min.ord. €/cad
Conf.
Pressure
Part No. Connection Options Box/Master Min.order
Range
-1/0 bar G1/4B 100/100 100 12,30
0-1 bar G1/4B 100/100 100 11,10
0-1.6 bar G1/4B 100/100 100 11,10
0-2.5 bar G1/4B 100/100 100 7,80
PZFEA2204BB10 0-4 bar G1/4B R+LW 10/100 10 7,80
PZFEA2206BB13 0-6 bar G1/4B R+LW 10/100 10 7,80
PZFEA2210BB12 0-10 bar G1/4B R+LW 10/100 10 7,80
PZFEA2216BB09 0-16 bar G1/4B R+LW 10/100 10 7,80
PZFEA2225BB04 0-25 bar G1/4B R+LW 10/100 10 7,80
PZFEA2240BB00 0-40 bar G1/4B R+LW 10/100 10 7,80
0-60 bar G1/4B 100/100 100 11,50
0-100 bar G1/4B 100/100 100 11,50
0-160 bar G1/4B 100/100 100 11,50
0-250 bar G1/4B 100/100 100 11,50
0-315 bar G1/4B 100/100 100 11,50
0-400 bar G1/4B 100/100 100 11,50
Legenda opzioni vedere pag.83/Options legend see pag.83
