MANOMETRI/PRESSURE GAUGES CAPITOLO 1/CHAPTER 1

MG3A-INOX 100
Glicerina cassa inox DN100 attacco posteriore-Glycerine filled stainless steel case DN100 centre back entry.
Min.
Codice Scala Attacco Opzioni Imballo/Conf. €/cad
ord.
Pressure Min.
Part No. Connection Options Box/Master
Range order
-76-0 cm Hg 1/12 12 80,20
PF509916LF -1/0 bar/in Hg G1/2B D+LW 1/12 1 80,20
-1/0.6 bar 1/12 12 80,20
PF5403DL00 -1+1.5 bar/in hg G1/2B D 1/12 1 80,20
-1+3 bar 1/12 12 80,20
PF5406DL00 -1+5 bar G1/2B D 1/12 1 80,20
-1+9 bar 1/12 12 80,20
-1+15 bar 1/12 12 80,20
PF540116LF 0-1 bar/psi G1/2B D+LW+Z0 1/12 1 76,10
0-1.6 bar/psi G1/2B 1/12 12 76,10
PF550316LF 0-2.5 bar/psi G1/2B D+LW 1/12 1 73,20
PF550416LF 0-4 bar/psi G1/2B D+LW 1/12 1 73,20
PF550616LF 0-6 bar/psi G1/2B D+LW 1/12 1 73,20
PF551016LF 0-10 bar/psi G1/2B D+LW 1/12 1 73,20
PF551216LF 0-12 bar/psi G1/2B D+LW 1/12 1 73,20
PF551616LF 0-16 bar/psi G1/2B D+LW 1/12 1 73,20
PF552016LF 0-20 bar/psi G1/2B D+LW 1/12 1 73,20
PF552516LF 0-25 bar/psi G1/2B D+LW 1/12 1 73,20
PF554016LF 0-40 bar/psi G1/2B D+LW 1/12 1 73,20
PF564416LF 0-60 bar/psi G1/2B D+LW 1/12 1 74,90
PF564816LF 0-100 bar/psi G1/2B D+LW 1/12 1 74,90
PF565416LF 0-160 bar/psi G1/2B D+LW 1/12 1 74,90
PF566016LF 0-250 bar/psi G1/2B D+LW 1/12 1 74,90
PF566216LF 0-315 bar/psi G1/2B D+LW 1/12 1 74,90
PF566616LF 0-400 bar/psi G1/2B D+LW 1/12 1 74,90
PF567016LF 0-600 bar/psi G1/2B D+LW 1/12 1 74,90

Legenda opzioni vedere pag.83/Options legend see pag.83

OPZIONI SOGGETTE A LOTTO MINIMO/OPTIONS SUBJECT TO MINIMUM QUANTITY

MG3A-INOX 50/63
S INOX 50 PZMINACC050 staffa per montaggio a pannello fornita Mounting bracket supplied
separatamente separately
S INOX 63 PMINACC047 staffa per montaggio a pannello fornita Mounting bracket supplied
separatamente separately

MG3A-INOX 63/100
Z Foro di passaggio 0.5 mm per scale < 40 bar Restrictor hole 0.5 mm for range < 40 bar
Z0 Foro di passaggio 3 mm per scale ≥ 40 bar Without restrictor hole 3 mm for range ≥ 40 bar

RN Riempimento nullo per temperature ambientali tra -20+60°C Zero filling for ambient temperatures -20+60°C
T2 Riempimento nullo per temperature ambientali tra -20+90°C Zero filling for ambient temperatures -20+90°C

MG3A-INOX 63
VC Trasparente resistente alle sostanze chimiche a richiesta Chemical window on request

MG3A-INOX 50/63/100
QL Quadranti personalizzati, altre scale e attacchi a richiesta Customized dials, other scale ranges on request
