A VENTILAZIONE RESIDENZIALE

DATI TECNICI

PRODOTTI CODICI V ~ 50HZ W A RPM PORTATA MAX PRESSIONE MAX °C* KG
min/med/ min/med/ min/med/ m /h l/s mmH O Pa MAX
3
2
max max max min/med/max min/med/max min/med/max min/med/max
QE 60 LL 11521
QE 60 LL T 11526
QE 60 LL TP 11532 220 - 240 16 0.14 1170 60 16.7 35 343 50 2.33
QE 60 LL TP HCS 11537
QE 60 LL T PIR 11544
QE 60/35 LL 11523
QE 60/35 LL T 11528
9 0.11 855 35 9.7 10 98
QE 60/35 LL TP 11534 220 - 240 50 2.33
16 0.14 1170 60 16.7 35 343
QE 60/35 LL TP HCS 11541
QE 60/35 LL T PIR 11546
QE 100 LL 11522
QE 100 LL T 11527
QE 100 LL TP 11533 220 - 240 26 0.17 1570 100 27.8 36 353 50 2.33
QE 100 LL TP HCS 11538
QE 100 LL T PIR 11545
QE 100/60 LL 11524
QE 100/60 LL T 11531
16 0.14 1170 60 16.7 35 343
QE 100/60 LL TP 11535 220 - 240 50 2.33
26 0.17 1570 100 27.8 36 353
QE 100/60 LL TP HCS 11542
QE 100/60 LL T PIR 11547
QE 100/60/35 LL 11525 9 0.11 855 35 9.7 10 98
16
QE 100/60/35 LL TP 11536 220 - 240 26 0.14 1170 60 16.7 35 343 50 2.33
9 017 1570 100 27.8 36 353
QE 100/60/35 LL TP HCS 11543
* Temperatura massima di funzionamento continuo del prodotto.

LIVELLI SONORI

POTENZA SONORA
LwA
INSTALLAZIONE A PARETE INSTALLAZIONE A INCASSO
Portata m /h 100 60 35 Portata m /h 100 60 35
3
3
dB(A) 50.5 43.7 33.7 dB(A) 50.2 42 32.7

PRESSIONE SONORA*
Lp dB(A) 2m
INSTALLAZIONE A PARETE INSTALLAZIONE A INCASSO
3
3
Portat m /h 100 60 35 Portata m /h 100 60 35
dB(A) 39.0 32.2 22.2 dB(A) 38.7 30.5 21.2
*Livello di pressione sonora misurata a 2 m, distribuzione emisferica.
