PhoNoFire®
Raccordi in PPC con cariche rinforzanti

Braga HTEA
•Branch HTEA
•Embranchement HTEA
•Abzweigung HTEA
•Derivación HTEA

codice d/d1 α z1 z2 z3 L Conf. €/1
205858W 58/58 45° 13 75 75 150 4 19,93
255858W 58/58 67°30’ 24 48 48 132 4 19,66
305858W 58/58 87°30’ 36 40 40 136 4 21,00
207858W 78/58 45° 6 92 89 164 4 18,29
207878W 78/78 45° 16 99 99 186 4 19,79
257858W 78/58 67°30’ 24 58 53 146 4 19,66
257878W 78/78 67°30’ 29 63 63 162 4 19,43
307858W 78/58 87°30’ 37 49 40 146 4 18,29
307878W 78/78 87°30’ 46 47 47 162 4 19,79
209058W 90/58 45° 1 97 90 157 4 23,35
309058W 90/90 87°30’ 36 53 40 142 4 23,35
209090W 90/90 45° 21 109 109 196 4 23,44
309090W 90/990 87°30’ 51 53 53 169 4 23,44
201158W 110/58 45° -7 115 104 179 4 22,75
251158W 110/58 67°30’ 14 84 65 150 4 22,31
301158W 110/58 87°30’ 35 62 40 147 4 22,75
201178W 110/78 45° 21 124 116 192 4 24,74
251178W 110/78 67°30’ 24 86 76 171 4 26,54
301178W 110/78 87°30’ 45 64 52 169 4 26,93
201111W 110/110 45° 25 134 134 232 4 27,07
251111W 110/110 67°30’ 42 89 89 201 4 27,23
301111W 110/110 87°30’ 60 66 66 200 4 27,07
201311W 135/110 45° 15 159 149 255 4 41,20
301311W 135/110 87°30’ 64 78 66 219 4 41,20
201313W 135/135 45° 32 168 168 292 4 49,47
301313W 135/135 87°30’ 71 81 81 243 4 51,97
201611W 160/110 45° 0 176 160 255 1 66,46
201616W 160/160 45° 36 193 193 322 1 101,53
301616W 160/160 87°30’ 84 89 89 265 1 123,65
202016W 200/160 45° 20 231 223 343 1 155,45
202020W 200/200 45° 47 240 240 385 1 181,09

Braga a fl usso avviato
•Swept-entry branch
•Embranchement avec départ coudé
•Bogenabzweig
•Derivación directa

codice d/d1 z1 z2 z3 L Conf. €/1
221190W 110/90 57 57 82 188 4 27,36
221111W 110/110 73 61 82 207 4 29,78
