Page 41 - COES - LISTINO 2018
P. 41
Coesprene®
Raccordi PP
Braga doppia HTDA
•Double branch HTDA
•Embranchement double HTDA
•Doppel-Abzweigung HTDA
•Derivación doble HTDA
codice d/d1/d2 α z1 z2 z3 L Conf. €/1
F9PBD0505 50/50/50 67,5° 11,6 40 41 113 10 22,68
F9PBD4904 90/40/40 45° 7 89 81 148 10 24,55
F9PBD4905 90/50/50 45° 7 89 91 148 10 26,87
F9PBD1104 110/40/40 67,5° 12 69 46 113 10 20,56
F9PBD8104 110/40/40 87° 12 69 26 113 10 20,56
F9PBD4105 110/50/50 45° 17 103 91 145 10 27,32
F9PBD1105 110/50/50 67,5° 8 71 51 135 10 26,09
F9PBD8105• 110/50/50 87,5° 8 73 54 131 10 26,09
F9PBD1111• 110/110/110 67,5° 40 85 85 201 10 37,41
F9PBD8111 110/110/110 87,5° 45 59 63 182 10 37,14
• Prefabbricata • Prefabricated • Préfabriqué • Vorgefertigt • Prefabricado
Braga a scagno a 67,50° HTED
•67,5° double corner branch HTED
•Embranchement à 67,5° HTED
•Eckdoppelabzweig mit 67,5° -Ausgang HTED
•Derivación doble a 67,5° HTED
codice d/d1/d2 α Z1 Z2 Z3 Z4 Z5 L Conf. €/1
F9PBS0115• 110/110/50 67,5° 10 48 54 71,5 53 156 10 74,07
F9PBS0151• 110/50/110 67,5° 10 48 54 71,5 85,5 188 10 74,07
F9PBS1105• 110/50/50 67,5° 40 86 86 85 53 202 10 74,07
F9PBS1111• 110/110/110 67,5° 40 86 86 85 85,5 202 10 74,07
• Prefabbricata • Prefabricated • Préfabriqué • Vorgefertigt • Prefabricado
Ispezione con tappo a vite HTRE
•Inspection with screw cap HTRE
•Visite avec bouchon à vis HTRE
•Inspektionsöffnung mit Schraubstopfen HTRE
•Inspección, con tapón de rosca HTRE
codice d d1 L L1 z Conf. €/1
F9PIL0505 50 50 115 80 55 20 8,23
F9PIL0707 75 75 142 96 66 20 10,62
F9PIL0909 90 100 170 107 75 10 14,01
F9PIL1111 110 103 185 119 82 10 14,00
F9PIL1212 125 103 214 135 97 10 67,71
F9PIL1616 160 120 228 158 117 10 99,12
building the future together 39
