CAPITOLO 11.3 PROTEZIONE DELLE RETI IDRICHE

Elettrovalvole

WKB2

Elettrovalvola a membrana, comando indiretto, normalmente chiusa, 2 vie. Corpo ottone.
Sistema interno ottone e acciaio inossidabile. Raccordi F/F.
Membrana EPDM (-10°C÷140°C). Membrana elastomero fluorato (FKM) (-10°C÷140°C).
Protezione: IP65 con connettore (incluso nella confezione).
In opzione: comando manuale.
Approvazioni: ACS (Attestation de Conformite Sanitaire), EMC 2014/30/UE, LVD 2014/35/
UE.
DN Pz.
Codice Bobina DN" Caratteristica Imballo €/cad
mm Conf.
149B6967 30E: 220/230V-50/60HZ-8VA 10 3/8 EPDM - 220V/50Hz ac 1 1 83,10
149B6968 30E: 220/230V-50/60HZ-8VA 15 1/2 EPDM - 220V/50Hz ac 1 1 83,10
149B6969 30E: 220/230V-50/60HZ-8VA 20 3/4 EPDM - 220V/50Hz ac 1 1 128,00
149B6970 30E: 220/230V-50/60HZ-8VA 25 1 EPDM - 220V/50Hz ac 1 1 150,50
149B6971 30E: 220/230V-50/60HZ-8VA 32 1 1/4 EPDM - 220V/50Hz ac 1 1 240,10
149B6972 20E: 220/230V-50/60HZ-15VA 40 1 1/2 EPDM - 220V/50Hz ac 1 1 273,90
149B6973 20E: 220/230V-50/60HZ-15VA 50 2 EPDM - 220V/50Hz ac 1 1 339,10
149B6974 30E: 220/230V-50/60HZ-8VA 15 1/2 FKM - 220V/50Hz ac 1 1 105,50
149B6975 30E: 220/230V-50/60HZ-8VA 20 3/4 FKM - 220V/50Hz ac 1 1 150,40
149B6976 30E: 220/230V-50/60HZ-8VA 25 1 FKM - 220V/50Hz ac 1 1 170,80
149B6977 30E: 220/230V-50/60HZ-8VA 32 1 1/4 FKM - 220V/50Hz ac 1 1 262,70
149B6978 20E: 220/230V-50/60HZ-15VA 40 1 1/2 FKM - 220V/50Hz ac 1 1 296,20
149B6979 20E: 220/230V-50/60HZ-15VA 50 2 FKM - 220V/50Hz ac 1 1 361,30
149B6980 30B: 24V-50/60HZ-8VA 10 3/8 EPDM - 24V/50Hz ac 1 1 83,10
149B6981 30B: 24V-50/60HZ-8VA 15 1/2 EPDM - 24V/50Hz ac 1 1 83,10
149B6982 30B: 24V-50/60HZ-8VA 20 3/4 EPDM - 24V/50Hz ac 1 1 128,00
149B6983 30B: 24V-50/60HZ-8VA 25 1 EPDM - 24V/50Hz ac 1 1 150,50
149B6984 30B: 24V-50/60HZ-8VA 32 1 1/4 EPDM - 24V/50Hz ac 1 1 240,10
149B6985 20B: 24V-50/60HZ-15VA 40 1 1/2 EPDM - 24V/50Hz ac 1 1 273,90
149B6986 20B: 24V-50/60HZ-15VA 50 2 EPDM - 24V/50Hz ac 1 1 339,10
149B6987 30B: 24V-50/60HZ-8VA 15 1/2 FKM - 24V/50Hz ac 1 1 105,50
149B6988 30B: 24V-50/60HZ-8VA 20 3/4 FKM - 24V/50Hz ac 1 1 150,40
149B6989 30B: 24V-50/60HZ-8VA 25 1 FKM - 24V/50Hz ac 1 1 170,80
149B6990 30B: 24V-50/60HZ-8VA 32 1 1/4 FKM - 24V/50Hz ac 1 1 262,70
149B6991 20B: 24V-50/60HZ-15VA 40 1 1/2 FKM - 24V/50Hz ac 1 1 296,20
149B6992 20B: 24V-50/60HZ-15VA 50 2 FKM - 24V/50Hz ac 1 1 361,30
149B6993 301: 24V/DC-6,5W 10 3/8 EPDM - 24V dc 1 1 83,10
149B6994 301: 24V/DC-6,5W 15 1/2 EPDM - 24V dc 1 1 83,10
149B6995 301: 24V/DC-6,5W 20 3/4 EPDM - 24V dc 1 1 128,00
149B6996 301: 24V/DC-6,5W 25 1 EPDM - 24V dc 1 1 150,50
149B6997 301: 24V/DC-6,5W 32 1 1/4 EPDM - 24V dc 1 1 240,10
149B6998 201: 24V/DC-10W 40 1 1/2 EPDM - 24V dc 1 1 273,90
149B6999 201: 24V/DC-10W 50 2 EPDM - 24V dc 1 1 339,10
149B12400 301: 24V/DC-6,5W 15 1/2 FKM - 24V dc 1 1 105,50
149B12401 301: 24V/DC-6,5W 20 3/4 FKM - 24V dc 1 1 150,40
149B12402 301: 24V/DC-6,5W 25 1 FKM - 24V dc 1 1 170,80
149B12403 301: 24V/DC-6,5W 32 1 1/4 FKM - 24V dc 1 1 262,70
149B12404 201: 24V/DC-10W 40 1 1/2 FKM - 24V dc 1 1 296,20
149B12405 201: 24V/DC-10W 50 2 FKM - 24V dc 1 1 361,30
Dimensioni a pag.469
