Indici energetici (Reg. 2016/2281 UE)
Taglia 1101 1251 1401 1601 1801 2101 2401 2502 2801 2802 3201 3202 3602 4202 4802 5602 6402 6703 7203 8403 9603
Modello: H
SEER - 12/7 (EN14825: 2018) - gas refrigerante R134a (1)
° % - - - - - - - - - - - - - - - - - 279,70 281,00 284,80 278,60
Efficienza stagionale
A % 306,80 310,90 296,50 309,10 297,30 306,60 308,50 298,00 314,60 297,10 315,60 301,30 295,40 301,80 303,60 307,30 298,00 297,80 295,60 296,90 297,50
° W/W - - - - - - - - - - - - - - - - - 7,07 7,10 7,20 7,04
SEER
A W/W 7,75 7,85 7,49 7,80 7,51 7,74 7,79 7,53 7,94 7,50 7,97 7,61 7,46 7,62 7,67 7,76 7,53 7,52 7,47 7,50 7,51
SEPR - (EN 14825: 2018) Alta temperatura - gas refrigerante R134a (2)
° W/W - - - - - - - - - - - - - - - - - 8,40 8,30 8,20 8,10
SEPR
A W/W 9,20 9,10 9,10 8,50 9,00 8,60 8,80 8,80 8,80 8,80 8,70 8,60 8,40 8,60 8,50 8,60 8,60 8,70 8,60 8,40 8,50
(1) Calcolo eseguito con portata d’acqua VARIABILE e temperatura d’uscita VARIABILE.
(2) Calcolo eseguito con portata d’acqua VARIABILE.
Dati elettrici
Taglia 1101 1251 1401 1601 1801 2101 2401 2502 2801 2802 3201 3202 3602 4202 4802 5602 6402 6703 7203 8403 9603
Modello: H
Gas R134a
° A - - - - - - - - - - - - - - - - - 954,0 1052,0 1180,0 1290,0
Corrente massima (FLA)
A A 165,0 190,0 216,0 237,0 274,0 308,0 356,0 378,0 387,0 428,0 418,0 473,0 535,0 616,0 704,0 787,0 864,0 954,0 1357,0 1180,0 1290,0
° A - - - - - - - - - - - - - - - - - 1234,0 1357,0 1595,0 1784,0
Corrente di spunto (LRA)
A A 23,0 23,0 23,0 23,0 23,0 23,0 23,0 507,0 23,0 560,0 23,0 676,0 742,0 897,0 1009,0 1203,0 1359,0 1234,0 1052,0 1595,0 1784,0
DATI PRESTAZIONALI MOTOEVAPORANTI
Dati prestazionali modello (°) - per temperature di condensazione fino a 55°C
Dati rese modello WFI° - AE - gas R134a
Taglia 1101 1251 1401 1601 1801 2101 2401 2801 3201

Modello: °
Prestazioni in raffreddamento 12 °C / 7 °C - gas R134a (1)
Potenza frigorifera kW 261,4 307,5 351,6 393,3 441,4 493,3 571,6 642,9 693,1
Potenza assorbita kW 68,4 80,8 90,0 100,3 117,7 133,8 145,8 164,9 178,0
Corrente assorbita totale a freddo W/W 119,0 139,0 152,0 168,0 197,0 222,0 240,0 269,0 292,0
A
3,75
3,81
3,89
3,90
3,91
3,92
3,82
EER
3,69
3,92
ACQUA-ACQUA Portata acqua evaporatore kPa 44906 52830 60402 67574 75833 84756 98206 110455 119091 ACQUA-ACQUA
l/h
37
21
31
36
36
21
20
28
27
Perdita di carico lato evaporatore
Lunghezza linee frigorifere da/a 0 - 10 m
Linea del gas (C1)
-
-
Linea del gas (C2) Ø Ø 54,0 67,0 67,0 67,0 76,0 76,0 89,0 89,0 89,0
-
-
-
-
-
-
-
Linea del gas (C3) Ø - - - - - - - - -
Linea del liquido (C1) Ø 35,0 42,0 42,0 42,0 42,0 54,0 54,0 54,0 54,0
Linea del liquido (C2) Ø - - - - - - - - -
Linea del liquido (C3) Ø - - - - - - - - -
(1) Acqua lato utenza 12 °C / 7 °C; Temperatura di condensazione 45 °C

Taglia 2502 2802 3202 3602 4202 4802 5602 6402 6703 7203 8403 9603
Modello: °
Prestazioni in raffreddamento 12 °C / 7 °C - gas R134a (1)
Potenza frigorifera kW 603,1 688,5 797,4 899,3 1008,4 1169,8 1287,8 1439,2 1558,1 1742,4 1896,4 2110,0
Potenza assorbita kW 152,9 171,4 198,1 229,9 259,8 287,4 323,9 364,6 386,3 431,2 481,0 540,3
Corrente assorbita totale a freddo A 261,4 292,5 330,2 380,6 424,7 476,4 532,4 600,3 631,3 709,7 792,6 891,2
EER W/W 3,94 4,02 4,03 3,91 3,88 4,07 3,98 3,95 4,03 4,04 3,94 3,91

Portata acqua evaporatore l/h 103615 118287 137003 154508 173247 200980 221262 247268 267705 299365 325826 362526
Perdita di carico lato evaporatore kPa 43 35 29 22 25 35 25 31 35 43 39 24
Lunghezza linee frigorifere da/a 0 - 10 m
Linea del gas (C1) Ø 67,0 67,0 67,0 76,0 76,0 88,9 88,9 88,9 76,0 88,9 88,9 88,9
Linea del gas (C2) Ø 67,0 67,0 67,0 76,0 76,0 88,9 88,9 88,9 76,0 88,9 88,9 88,9
Linea del gas (C3) Ø - - - - - - - 42,0 76,0 88,9 88,9 88,9
Linea del liquido (C1) Ø 42,0 42,0 42,0 42,0 54,0 54,0 54,0 54,0 54,0 54,0 54,0 54,0
Linea del liquido (C2) Ø 42,0 42,0 42,0 42,0 54,0 54,0 54,0 54,0 54,0 54,0 54,0 54,0

Linea del liquido (C3) Ø - - - - - - - - 54,0 54,0 54,0 54,0
(1) Acqua lato utenza 12 °C / 7 °C; Temperatura di condensazione 45 °C
