RACCORDI IN OTTONE

RACCORDI A COMPRESSIONE PER TUBO PEX
Massima pressione di lavoro: PN 16 a 60°C.
Temperatura massima di lavoro: 95°C.
Applicazioni: valido per la distribuzione a pressione di fluidi non alimentari con temperature non superiori a 80°C (ad esempio impianti di riscaldamento) e
fluidi alimentari e per uso sanitario (ad esempio strutture igienico-sanitarie).

RACCORDO RACCORDO FEMMINA
DOPPIO DRITTO DRITTO

Ø COD. E Ø COD. E
12 x 12 x 2.0 100 10 TR8RD012 6,85 3/8” x 12 x 2.0 150 10 TR8RH122 3,65
15 x 15 x 2.5 100 10 TR8RD015 6,65 1/2” x 12 x 2.0 150 10 TR9RH123 4,05
16 x 16 x 2.0 100 10 TR9RD016 6,70 1/2” x 15 x 2.5 150 10 TR8RH153 3,65
16 x 16 x 2.2 100 10 TR8RD016 6,35 1/2” x 16 x 2.0 150 10 TR9RH163 3,85
18 x 18 x 2.5 80 10 TR8RD018 8,55 1/2” x 16 x 2.2 150 10 TR8RH163 3,85
20 x 20 x 2.0 60 10 TR9RD020 10,90 1/2” x 18 x 2.5 100 10 TR8RH183 5,25
20 x 20 x 2.8 60 10 TR8RD020 10,60 1/2” x 20 x 2.0 80 10 TR9RH203 6,05
22 x 22 x 3.0 50 5 TR8RD022 12,00 1/2” x 20 x 2.8 80 10 TR8RH203 6,10
25 x 25 x 2.3 40 5 TR9RD025 15,45 1/2” x 22 x 3.0 60 10 TR8RH223 7,55
25 x 25 x 3.5 40 10 TR8RD025 15,60 3/4” x 16 x 2.0 100 10 TR9RH164 4,60
32 x 32 x 3.0 25 1 TR9RD032 24,15 3/4” x 16 x 2.2 100 10 TR8RH164 4,60
3/4” x 18 x 2.5 80 10 TR8RH184 5,40
3/4” x 20 x 2.0 80 10 TR9RH204 6,30
RACCORDO MASCHIO 3/4” x 20 x 2.8 80 10 TR8RH204 6,05
DRITTO 3/4” x 22 x 3.0 70 10 TR8RH224 7,95
3/4” x 25 x 2.3 50 10 TR9RH254 11,20
3/4” x 25 x 3.5 50 5 TR8RH254 10,75
Ø COD. E 3/4” x 32 x 3.0 40 5 TR9RH324 13,95
1” x 25 x 2.3 40 5 TR9RH255(1) 11,95
3/8” x 12 x 2.0 170 10 TR8RM122 3,65 1” x 25 x 3.5 40 5 TR8RH255 13,15
1/2” x 12 x 2.0 170 10 TR8RM123 3,55 1” x 32 x 3.0 40 1 TR9RH325 15,85
1/2” x 15 x 2.5 160 10 TR8RM153 3,55
1/2” x 16 x 2.0 160 10 TR9RM163 3,55
1/2” x 16 x 2.2 160 10 TR8RM163 3,55
1/2” x 18 x 2.5 100 10 TR8RM183 4,80
1/2” x 20 x 2.0 100 10 TR9RM203 5,80 GOMITO DOPPIO
1/2” x 20 x 2.8 100 10 TR8RM203 5,85
1/2” x 22 x 3.0 60 10 TR8RM223 7,75
3/4” x 16 x 2.0 120 10 TR9RM164 4,25 Ø COD. E
3/4” x 16 x 2.2 120 10 TR8RM164 4,25
3/4” x 18 x 2.5 100 10 TR8RM184 5,20 12 x 12 x 2.0 80 10 TR9CD012 7,60
3/4” x 20 x 2.0 80 10 TR9RM204 5,70 15 x 15 x 2.5 80 10 TR8CD015 7,20
3/4” x 20 x 2.8 80 10 TR8RM204 5,65 16 x 16 x 2.0 80 10 TR9CD016 7,15
3/4” x 22 x 3.0 60 10 TR8RM224 7,00 16 x 16 x 2.2 80 10 TR8CD016 7,40
3/4” x 25 x 2.3 50 10 TR9RM254 10,55 18 x 18 x 2.5 60 10 TR8CD018 10,75
3/4” x 25 x 3.5 50 10 TR8RM254 11,00 20 x 20 x 2.0 50 10 TR9CD020 12,00
3/4” x 32 x 3.0 40 5 TR9RM324 14,50 20 x 20 x 2.8 50 10 TR8CD020 12,20
1” x 25 x 2.3 40 5 TR9RM255 12,70 22 x 22 x 3.0 40 10 TR8CD022 14,50
1” x 25 x 3.5 40 10 TR8RM255 12,55 25 x 25 x 2.3 20 5 TR9CD025 20,05
1” x 32 x 3.0 40 1 TR9RM325 15,30 25 x 25 x 3.5 20 5 TR8CD025 (1) 20,75
32 x 32 x 3.0 20 1 TR9CD032 30,00

CURVA 100º CURVA 105º

Ø COD. E Ø COD. E
1/2” x 16 x 2.0 70 10 TR9A0163 5,95 1/2” x 16 x 2.0 70 10 TR9A5163 6,55
1/2” x 16 x 2.2 70 10 TR8A0163 5,95
(1) Fino ad esaurimento scorte.
