Sistema a cartellare
Flanging system

Nipplo ridotti M/M in ottone con doppia filettatura maschio ISO 228 G a battuta piana (A-B)
A B
Brass M/M reduced nipples with double ISO 228 G male thread with plane end (A-B)

Codice DN Fil. connessione Pz./conf. €/confez. €/Pz. Conf./box
Code Connection thread Pcs./pack €/pack €/Pcs Packs/box
A B
A03-0005-04567 20-25 G 1" G 1" 1/4 5 119,40 23,88 -

* i raccordi DN 10 sono idonei esclusivamente alla connessione con il tubo CSST AISI 304.
* DN 10 fittings are only suitable for connection with PLT-CSST AISI 304 tube.

Nipplo ridotti M/M in ottone con filettatura maschio ISO 228 G a battuta piana (B) e
filettatura maschio conica EN 10226 R (A)
A B
Brass M/M reduced nipples with ISO 228 G male thread with plane end (B) and EN 10226 R
male taper thread (A)

Codice DN Fil. connessione Pz./conf. €/confez. €/Pz. Conf./box
Code Connection thread Pcs./pack €/pack €/Pcs Packs/box
A B Pompe di calore / Heat pumps
A03-0005-00798 20 R 3/4" G 1" 5 52,60 10,52 -
A03-0005-00799 25 R 1" G 1" 1/4 5 88,70 17,74 -

Nipplo ridotti M/F in ottone con filettatura maschio ISO 228 G a battuta piana (A)
e filettatura femmina EN 10226 RP (B)
A B
Brass M/F reduced nipples with ISO 228 G male thread with plane end (A) and EN 10226 RP
female thread (B)

Codice DN Fil. connessione Pz./conf. €/confez. €/Pz. Conf./box
Code Connection thread Pcs./pack €/pack €/Pcs Packs/box
A B
A03-0005-04568 20 G 1" RP 1" 1/4 5 102,10 20,42 -

A Nipplo ridotti M/F in ottone con filettatura maschio ISO 228 G a battuta piana (A) e filetta-
tura femmina EN 10226 RP (B)
B Brass M/F reduced nipples with ISO 228 G male thread with plane end (A) and EN 10226 RP
female thread (B)

Codice DN Fil. connessione Pz./conf. €/confez. €/Pz. Conf./box
Code Connection thread Pcs./pack €/pack €/Pcs Packs/box
A B
A03-0005-00801 20 G 1" RP 3/4" 5 32,90 6,58 -
A03-0005-00802 25 G 1" 1/4 RP 1" 5 74,30 14,86 -

Sistemi di tubazioni per pompe di calore e collegamenti idronici / Tubing systems for heating pumps and hydronic connections 149
