Moduli termici a condensazione in armadio da interno e da esterno
POWER MAX BOX

Abbinamenti scambiatore a piastre per funzionamento caldaia portata nominale o massima
(∆T = 10 °C medio tra primario e secondario)

ARTICOLO Scambiatore a piastre ∆Tml = 10° C
80° 70°
SP 35-DN50 21 (21) N SP 35-DN50 27 (27) N SP 35-DN50 33 (33) N SP 35-DN50 41 (41) N SP 35-DN50 53 (53) N SP 35-DN50 61 (61) N SP 50-DN65 35 (14) N SP 50-DN65 45 (18) N SP 50-DN65 51 (21) N SP 60-DN100 41 (33) N SP 60-DN100 45 (36) N SP 60-DN100 51 (41) N SP 60-DN100 61 (49) N

20200611 20200613 20200614 20200615 20200618 20200619 20200635 20200638 20200640 20200648 20200658 20200659 20200663
60° 50°

POWER MAX BOX 130-2 P ●
POWER MAX BOX 160-2 P ●
POWER MAX BOX 200-2 P ●
POWER MAX BOX 260-2 P ●
POWER MAX BOX 300-2 P ●
POWER MAX BOX 330-3 P ●
POWER MAX BOX 390-3 P ●
POWER MAX BOX 450-3 P ●
POWER MAX BOX 520-4 P ●
POWER MAX BOX 600-4 P ●
POWER MAX BOX 750 ●
POWER MAX BOX 900 ●
POWER MAX BOX 1050 ●
POWER MAX BOX 1200 ●
POWER MAX BOX 1350 ●
POWER MAX BOX 1500 ●

Abbinamenti scambiatore a piastre per funzionamento caldaia portata nominale o massima
(∆T = 7,2 °C medio tra primario e secondario)

ARTICOLO Scambiatore a piastre ∆Tml = 7,2° C
85° 75°
SP 35-DN50 27 (27) N SP 35-DN50 33 (33) N SP 35-DN50 41 (41) N SP 35-DN50 53 (53) N SP 35-DN50 61 (61) N SP 35-DN50 71 (71) N SP 35-DN50 81 (81) N SP 35-DN50 89 (89) N SP 35-DN50 101 (101) N SP 50-DN65 55 (22) N SP 50-DN65 65 (26) N SP 50-DN65 79 (32) N SP 60-DN100 61 (49) N SP 60-DN100 77 (62) N SP 60-DN100 87 (70) N

20200613 20200614 20200615 20200618 20200619 20200620 20200621 20200622 20200623 20200642 20200645 20200647 20200663 20200667 20200670
65° 60°

POWER MAX BOX 130-2 P ●
POWER MAX BOX 160-2 P ●
POWER MAX BOX 200-2 P ●
POWER MAX BOX 260-2 P ●
POWER MAX BOX 300-2 P ●
POWER MAX BOX 330-3 P ●
POWER MAX BOX 390-3 P ●
POWER MAX BOX 450-3 P ●
POWER MAX BOX 520-4 P ●
POWER MAX BOX 600-4 P ●
POWER MAX BOX 750 ●
POWER MAX BOX 900 ●
POWER MAX BOX 1050 ●
POWER MAX BOX 1200 ●
POWER MAX BOX 1350 ●
POWER MAX BOX 1500 ●
