Page 74 - WAVIN - LISTINO GENERALE 2025
P. 74
Sistemi di adduzione Tigris, scarico e raccordi a pressione
Gomiti 90°
Codice Classe Dimensioni A A1 B B1 B2 C Conf. Euro
mm mm mm mm mm mm mm pz.
381004 E2 20 14,5 26,8 20 1,41
381005 E2 25 16,0 31,0 20 1,70
381006 E2 32 18,0 36,5 10 2,64
D
381007 E2 40 20,5 43,0 10 7,39
A
B
381008 E2 50 23,5 51,0 10 11,26
381009 E2 63 27,5 61,5 5 14,92
387007 E2 75 30,0 70,15 2 23,99
387009 E2 90 33,0 82,0 1 69,21
387010 E2 110 37,0 95,0 1 87,72
387011 E2 125 40 105,0 1 114,04 Tigris Green
Gomiti 90° PP-RCT S5/SDR 11 Saldatura T/T
Codice Classe Dimensioni A A1 B B1 B2 t Conf. Euro
mm mm mm mm mm mm mm pz.
387012 E2 160 103,0 210,0 14,6 1 229,80
387013 E2 200 115,0 239,0 18,2 1 568,89
A 387014 E2 250 116,0 259,0 22,7 1 1137,78
t
D
B
Gomito 90° maschio/femmina
Codice Classe Dimensioni D3 A A1 B B1 B2 C Conf. Euro
mm mm mm mm mm mm mm mm pz.
381244 E2 20 20 14,5 26,8 30,3 13,0 20 1,70
381245 E2 25 25 16,0 31,0 35,0 14,0 20 1,95
381246 E2 32 32 18,0 36,5 42,2 16,0 20 2,64
R Contattare il Customer Service per tempistiche sulla disponibilità
www.wavin.it Listino 2025 73
