Page 39 - WAVIN - LISTINO GENERALE 2025

Sistemi di adduzione Tigris, scarico e raccordi a pressione

T ridotti Tigris M5
B
A Codice A Ø A B Ø B C Ø C
up to 10 ± 1º 120 - 400 ± 0º10'
10 - 50 ± 0º30' over 400 ± 0º5'
x Spess. Profilo x Spess. Profilo x Spess. Profilo
angular dimensions; 50 - 120 ± 0º20'
Tigris M1-M5
4064356 20x2 0,5 - 3 ± 0,2 broken edges; 3 - 6 ± 0,5 over 6 ± 1 U-H-TH-B-UP 16x2 U-H-TH-B-UP 16x2 U-H-TH-B-UP
C 4064357 20x2 0,5 - 3 ± 0,1 30 - 120 ± 0,3 1000 - 2000 ± 1,2 3 - 6 ± 0,1 120 - 400 ± 0,5 2000 - 4000 ± 2 U-H-TH-B-UP 16x2 U-H-TH-B-UP 20x2 U-H-TH-B-UP
4064358 20x2 linear dimensions; 6 - 30 ± 0,2 400 - 1000 ± 0,8 U-H-TH-B-UP 20x2 U-H-TH-B-UP 16x2 U-H-TH-B-UP
ISO 2768-m
4064353 20x2,25 U-H-TH-B-UP 16x2 U-H-TH-B-UP 16x2 U-H-TH-B-UP
UNDER EDITING

0 First Edition 4064354 CH 20x2,25 U-H-TH-B-UP 16x2 U-H-TH-B-UP 20x2,25 U-H-TH-B-UP
This Document contains confidential information of Wavin.No reproduction or disclosure of any part hereof to third parties or use hereof is allowed at any time without authorisation
in writing by Wavin. All rights are vested in Wavin B.V.,Zwolle, The Netherlands.
Rev. Description Date Drawn Checked
Material: Volume (cm^3): Status: Units: Tolerances: Projection: Scale: Format:
CONCEPT mm ISO 2768-m 2:1 A3
4064355
20x2,25
Description: Drawn:
M5 Tee Assembly 20x16x20 Date: 19-04-18 U-H-TH-B-UP 20x2,25 U-H-TH-B-UP 16x2 U-H-TH-B-UP
CH
Drawing No: Article No: Sheet: Revison:
Wavin Technology & Innovation BV 17-5415 2 of 2 0
4064359 25x2,5 U-H-TH-UP 20x2,25 U-H-TH-B-UP 20x2,25 U-H-TH-B-UP
4064361 25x2,5 U-H-TH-UP 16x2 U-H-TH-B-UP 25x2,5 U-H-TH-UP
4064362 25x2,5 U-H-TH-UP 20x2,25 U-H-TH-B-UP 25x2,5 U-H-TH-UP
4064367 26x3 H-TH-B 16x2 U-H-TH-B-UP 26x3 H-TH-B
4064368 26x3 H-TH-B 20x2 U-H-TH-B-UP 20x2 U-H-TH-B-UP
4064369 26x3 H-TH-B 20x2 U-H-TH-B-UP 26x3 H-TH-B
4064372 32x3 U-H-TH-B-UP 20x2,25 U-H-TH-B-UP 32x3 U-H-TH-B-UP
4064373 32x3 U-H-TH-B-UP 25x2,5 U-H-TH-UP 25x2,5 U-H-TH-UP
4064374 32x3 U-H-TH-B-UP 25x2,5 U-H-TH-UP 32x3 U-H-TH-B-UP
4064376 32x3 U-H-TH-B-UP 20x2 U-H-TH-B-UP 32x3 U-H-TH-B-UP
4064377 32x3 U-H-TH-B-UP 26x3 H-TH-B 26x3 H-TH-B
4064378 32x3 U-H-TH-B-UP 26x3 H-TH-B 32x3 U-H-TH-B-UP
4064384 40x4 U-TH-UP 20x2 U-H-TH-B-UP 40x4 U-TH-UP
4064380 40x4 U-TH-UP 25x2,5 U-H-TH-UP 40x4 U-TH-UP

4064385 40x4 U-TH-UP 26x3 H-TH-B 40x4 U-TH-UP
4064381 40x4 U-TH-UP 32x3 U-H-TH-B-UP 40x4 U-TH-UP

T ridotti Tigris M1
B
Codice A Ø A B Ø B C Ø C
A x Spess. Profilo x Spess. Profilo x Spess. Profilo
C
343757 40x4 U 25x2,5 U 40x4 U
343767 40x4 U 32x3 U 40x4 U
343878 50x4,5 U 40x4 U 50x4,5 U
343979 63x6 U 40x4 U 63x6 U

38 Listino 2025
