80 SISTEMI DI RACCORDI A PRESSARE
Press Fitting Systems • Pressfittingsysteme • Systèmes de raccords a sertir • Sistema de accesorios para prensar

≤54 B 10 13
183/000 G
76÷108 B 10 14
MANICOTTO
• COUPLING
• MUFFE
• MANCHON
• MANGUITO HH
MATERIAL: AISI 316L – 1.4404
O-RING: HNBR giallo - yellow - Gelb - jaune -
amarillo

De
Z
L
CODE mm mm mm g €
183015000G 15 49 9 35 4 200 8,88
183018000G 18 50 10 42 4 200 10,13
183022000G 22 53 11 54 4 200 11,65
183028000G 28 56 10 71 4 100 13,34
183035000G 35 63 10 97 1 50 16,87
183042000G 42 72 12 136 1 40 22,87
183054000G 54 83 13 198 1 30 28,31
183076000G 76,1 142 32 635 1 4 137,94
183088000G 88,9 166 46 765 1 4 157,59
183108000G 108 203 41 1170 1 2 200,40

≤54 B 10 13
183/001 G
76÷108 B 10 14
MANICOTTO
PASSANTE
• SLIP COUPLING
• SCHIEBEMUFFE
• MANCHON LONG
• MANGUITO SIN TOPE
MATERIAL: AISI 316L – 1.4404
O-RING: HNBR giallo - yellow - Gelb - jaune -
amarillo
L
es
De
CODE mm mm mm g €
183015001G 15 81 25 56 4 200 17,61
183018001G 18 81 25 66 4 200 18,37
183022001G 22 84,5 25 83 4 200 21,31
183028001G 28 92 30 114 4 100 26,73
183035001G 35 102,5 30 153 1 50 34,36
183042001G 42 117,5 40 217 1 40 42,81
183054001G 54 139 40 321 1 30 54,79
183076001G 76,1 230 60 940 1 2 386,61
183088001G 88,9 260 70 1240 1 2 439,28
183108001G 108 310 80 1835 1 2 543,41

1/2025
